FREE SHIPPING on orders over $100
Offer price breaks when you order a larger quantify.
In Stock
Leading time would be depends on our work efficiency and delivery schedule, usually within 2 business days.
Specifications
| title | CP2B515-USAF-207TT |
| price | $ 596.33 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | ABB MOTORS AND MECHANICAL INC |
| Weight / kgm | 14.891 |
| Inch - Metric | Inch |
| Brand | DODGE |
| Weight / LBS | 26.6 |
| Other Features | Double Row | Closed End | Corrosion Resistant |
| Relubricatable | Yes |
| Global Part Number GPN | 522951 |
| Mounting Method | Adapter Sleeve |
| Length Thru Bore | 5.203 Inch | 132.156 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 8.8 Inch | 223 Millimeter |
| Bolt Spacing Minimum | 8.625 Inch | 219.075Millimeter |
| Base to Center Height | 3.25 Inch | 82.55 Millimeter |
| Bolt Spacing Maximum | 9.625 Inch | 244.475Millimeter |
| Housing Style | 2 Bolt Pillow Block |
| Insert Part Number | BRG22215KC3 |
| Number of Mounting Holes | 2 |
| Expansion / Non-expansion | Non-expansion |
| Seals | Triple Tect |
| Housing Material | Cast Iron |
| Mounting Bolts | 5/8 Inch |
| Housing Configuration | 2 Piece Split |
