Specifications
| title | TAPK15K208SEB |
| price | $ 739.47 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | QM INDUSTRIES |
| Inch - Metric | Inch |
| Brand | QM INDUSTRIES |
| Weight / LBS | 29 |
| Other Features | Double Row | Extreme Duty |
| Relubricatable | Yes |
| Global Part Number GPN | 504078 |
| Mounting Method | Tapered Adapter Sleeve |
| Length Thru Bore | 2.87 Inch | 72.898 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 9.8 Inch | 248.9 Millimeter |
| Bolt Spacing Minimum | 9.06 Inch | 230.124Millimeter |
| Base to Center Height | 3.5 Inch | 88.9 Millimeter |
| Bolt Spacing Maximum | 10.44 Inch | 265.176Millimeter |
| Housing Style | 4 Bolt Pillow Block |
| Insert Part Number | 22215 |
| Number of Mounting Holes | 4 |
| Expansion / Non-expansion | Expansion |
| Seals | Double Lip Nitrile Rubber |
| Housing Material | Cast Steel |
| Mounting Bolts | 3/4 Inch |
| Housing Configuration | 1 Piece Solid |
