Specifications
| title | PEU3K55 |
| price | $ 4,665.80 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | REXNORD |
| Weight / kgm | 40.823 |
| Inch - Metric | Inch |
| Brand | LINK BELT |
| Weight / LBS | 82 |
| Other Features | Single Row | Heavy Duty | Standard Backing |
| Relubricatable | Yes |
| Global Part Number GPN | 517170 |
| Mounting Method | Adapter Sleeve |
| Length Thru Bore | 3.969 Inch | 100.813 Millimeter |
| Actual Bolt Center to Center | 14.5 Inch | 368.3Millimeter |
| Nominal Bolt Center to Center | 14.5 Inch | 368 Millimeter |
| Bolt Spacing Minimum | 0 Inch | 0Millimeter |
| Base to Center Height | 5.688 Inch | 144.475 Millimeter |
| Bolt Spacing Maximum | 0 Inch | 0Millimeter |
| Housing Style | 2 Bolt Pillow Block |
| Insert Part Number | UG3K55L |
| Number of Mounting Holes | 2 |
| Expansion / Non-expansion | Expansion |
| Seals | Steel Clad Clearance |
| Housing Material | Cast Iron |
| Mounting Bolts | 1 Inch |
| Housing Configuration | 1 Piece Solid |
