FREE SHIPPING on orders over $100
Offer price breaks when you order a larger quantify.
In Stock
Leading time would be depends on our work efficiency and delivery schedule, usually within 2 business days.
Specifications
| title | PB220UR X 2S |
| price | $ 68.64 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | HUB CITY |
| Inch - Metric | Inch |
| Brand | HUB CITY |
| Weight / LBS | 5.9 |
| Other Features | Single Row | Spherical | Low Base | Has Trash Guard | Smaller Housing | With Set Screw |
| Relubricatable | Yes |
| Global Part Number GPN | 519854 |
| Mounting Method | Eccentric Collar |
| Length Thru Bore | 1.717 Inch | 43.612 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 6.3 Inch | 160 Millimeter |
| Bolt Spacing Minimum | 6.063 Inch | 154Millimeter |
| Base to Center Height | 2.188 Inch | 55.575 Millimeter |
| Bolt Spacing Maximum | 6.688 Inch | 169.875Millimeter |
| Housing Style | 2 Bolt Pillow Block |
| Insert Part Number | B220R |
| Number of Mounting Holes | 2 |
| Expansion / Non-expansion | Non-expansion |
| Seals | Nitrile Rubber |
| Housing Material | Cast Iron |
| Mounting Bolts | 5/8 Inch |
| Housing Configuration | 1 Piece Solid |
