Specifications
| title | FSYE 4.7/16 |
| price | $ 3,081.92 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | SKF |
| Weight / kgm | 30.557 |
| Inch - Metric | Inch |
| Brand | SKF |
| Weight / LBS | 71 |
| Other Features | Double Row | Heavy Duty | Double Collar | Open End | With Set Screw |
| Relubricatable | Yes |
| Global Part Number GPN | 501526 |
| Mounting Method | Concentric Collar |
| Length Thru Bore | 0 Inch | 0 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 13.2 Inch | 335.3 Millimeter |
| Bolt Spacing Minimum | 13.125 Inch | 333.375Millimeter |
| Base to Center Height | 4.75 Inch | 120.65 Millimeter |
| Bolt Spacing Maximum | 13.875 Inch | 352.425Millimeter |
| Housing Style | 4 Bolt Pillow Block |
| Number of Mounting Holes | 4 |
| Expansion / Non-expansion | Expansion |
| Seals | Trigard |
| Housing Material | Cast Iron |
| Mounting Bolts | 3/4 Inch |
| Housing Configuration | 1 Piece Solid |
