Specifications
| title | EP4B-IP-407R |
| price | $ 2,154.00 / each |
| Category | Pillow Block Bearings |
| UNSPSC | 31171511 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | ABB MOTORS AND MECHANICAL INC |
| Weight / kgm | 33.29 |
| Inch - Metric | Inch |
| Brand | DODGE |
| Weight / LBS | 73.32 |
| Other Features | Double Row | Has Flinger |
| Relubricatable | Yes |
| Global Part Number GPN | 522675 |
| Mounting Method | Adapter Sleeve |
| Length Thru Bore | 5.23 Inch | 132.842 Millimeter |
| Actual Bolt Center to Center | 0 Inch | 0Millimeter |
| Nominal Bolt Center to Center | 13.2 Inch | 335.3 Millimeter |
| Bolt Spacing Minimum | 13.25 Inch | 336.55Millimeter |
| Base to Center Height | 4.75 Inch | 120.65 Millimeter |
| Bolt Spacing Maximum | 13.75 Inch | 349.25Millimeter |
| Housing Style | 4 Bolt Pillow Block |
| Insert Part Number | INS-IP-407R |
| Number of Mounting Holes | 4 |
| Expansion / Non-expansion | Non-expansion |
| Seals | Triple Lip Contact |
| Housing Material | Cast Iron |
| Mounting Bolts | 3/4 Inch |
| Housing Configuration | 1 Piece Solid |
