Specifications
title | UCECH209TCMZ2 |
price | $ 180.62 / each |
Category | Hanger Unit Bearings |
UNSPSC | 31171513 |
Harmonized Tariff Code | 8483.20.40.40 |
Manufacturer Name | AMI BEARINGS |
Inch - Metric | Metric |
Brand | AMI BEARINGS |
Weight / LBS | 4.2 |
Bore | 1.772 Inch | 45 Millimeter |
EAN | 808250222551 |
Other Features | Single Row | Spherical | Corrosion Resistance | Wide Inner Race | Has Slinger |
Relubricatable | Yes |
Mounting Method | Set Screw |
Length Thru Bore | 1.937 Inch | 49.2 Millimeter |
Base to Center Height | 3.228 Inch | 82 Millimeter |
Housing Outside Diameter | 4.252 Inch | 108 Millimeter |
Housing Overall Length | 5.354 Inch | 136 Millimeter |
Mounting Thread | 1 Straight Pipe Female |
Insert Material | Zinc Coated Steel |
Housing Style | Hanger Unit |
Insert Part Number | UC209MZ2 |
Rating | Normal Duty |
Housing Material | Teflon Coated Cast Iron |
Expansion / Non-expansion | Non-expansion |
Seals | Single Lip Contact |
