Specifications
| title | UCECH205TC |
| price | $ 82.45 / each |
| Category | Hanger Unit Bearings |
| UNSPSC | 31171513 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | AMI BEARINGS |
| Inch - Metric | Metric |
| Brand | AMI BEARINGS |
| Weight / LBS | 1.56 |
| Bore | 0.984 Inch | 25 Millimeter |
| EAN | 808250379385 |
| Other Features | Single Row | Spherical | Corrosion Resistance | Wide Inner Race | Has Slinger |
| Relubricatable | Yes |
| Mounting Method | Set Screw |
| Length Thru Bore | 1.339 Inch | 34 Millimeter |
| Base to Center Height | 2.52 Inch | 64 Millimeter |
| Housing Outside Diameter | 2.756 Inch | 70 Millimeter |
| Housing Overall Length | 3.898 Inch | 99 Millimeter |
| Mounting Thread | 3/4 Straight Pipe Female |
| Insert Material | Steel |
| Housing Style | Hanger Unit |
| Insert Part Number | UC205 |
| Rating | Normal Duty |
| Housing Material | Teflon Coated Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Seals | Single Lip Contact |
