FREE SHIPPING on orders over $100
Offer price breaks when you order a larger quantify.
In Stock
Leading time would be depends on our work efficiency and delivery schedule, usually within 2 business days.
Specifications
| title | SCHB-LT7-200 |
| price | $ 418.69 / each |
| Category | Hanger Unit Bearings |
| UNSPSC | 31171513 |
| Harmonized Tariff Code | 8483.30.40.80 |
| Manufacturer Name | ABB MOTORS AND MECHANICAL INC |
| Weight / kgm | 2.157 |
| Inch - Metric | Inch |
| Brand | DODGE |
| Weight / LBS | 5.7 |
| Bore | 2 Inch | 50.8 Millimeter |
| EAN | 0782475017720 |
| Other Features | Self Lubricating |
| Relubricatable | No |
| Mounting Method | Slip Fit |
| Length Thru Bore | 1.625 Inch | 41.275 Millimeter |
| Base to Center Height | 3.25 Inch | 82.55 Millimeter |
| Housing Outside Diameter | 4.625 Inch | 117.475 Millimeter |
| Housing Overall Length | 5.563 Inch | 141.3 Millimeter |
| Mounting Thread | 1 Straight Pipe Female |
| Insert Material | Steel |
| Housing Style | Hanger Unit |
| Insert Part Number | INS-LT7-200 |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Non-expansion |
