Specifications
title | CREHBF-PN20 RMW |
price | $ 505.65 / each |
Category | Hanger Unit Bearings |
UNSPSC | 31171513 |
Harmonized Tariff Code | 8483.20.40.40 |
Manufacturer Name | MORSE INDUSTRIAL |
Inch - Metric | Inch |
Brand | MORSE INDUSTRIAL |
Weight / LBS | 3.15 |
Bore | 1.25 Inch | 31.75 Millimeter |
EAN | 662461352953 |
Other Features | Single Row | Spherical | Corrosion Resistance | Metal Land Riding Retainer | Has Flinger | External Lube |
Relubricatable | Yes |
Mounting Method | Set Screw |
Length Thru Bore | 1.688 Inch | 42.875 Millimeter |
Base to Center Height | 2.75 Inch | 69.85 Millimeter |
Housing Outside Diameter | 3.625 Inch | 92.075 Millimeter |
Housing Overall Length | 4.563 Inch | 115.9 Millimeter |
Mounting Thread | 3/4 Straight Pipe Female |
Insert Material | Black Oxide Coated Steel |
Housing Style | Hanger Unit |
Insert Part Number | PN-20 |
Rating | Normal Duty |
Housing Material | Teflon Coated Cast Iron |
Expansion / Non-expansion | Non-expansion |
Seals | High Performance Seal |
