Specifications
| title | SB 22220K C4 W33 |
| price | $ 721.13 / each |
| Category | Spherical Roller Bearings |
| UNSPSC | 31171510 |
| Harmonized Tariff Code | 84823040 |
| Manufacturer Name | REGAL BELOIT |
| Weight / kgm | 5.039 |
| Inch - Metric | Metric |
| Brand | MCGILL |
| Weight / LBS | 11.1 |
| Bore | 3.937 Inch | 100 Millimeter |
| EAN | 0726166007447 |
| Outside Diameter | 7.087 Inch | 180 Millimeter |
| Relubricatable | Yes |
| Seal Type | Open |
| Enclosure | Open |
| Global Part Number GPN | 479276 |
| Mounting Method | Adapter Mount |
| Cage Material | Steel |
| Width | 1.811 Inch | 46 Millimeter |
| Internal Clearance | C4-Extra Loose |
| Number of Rows of Rollers | Single Row |
| Withdrawal Sleeve | AHX320 (Specify bore) |
| Withdrawal Nut | KM22 |
| Adapter Part Number | SNW20 H320 HA20 HE320 (Specify Bore) Inch | H320 (Specify bore) Millimeter |
| Bore Profile | Tapered |
