FREE SHIPPING on orders over $100
Offer price breaks when you order a larger quantify.
In Stock
Leading time would be depends on our work efficiency and delivery schedule, usually within 2 business days.
Specifications
| title | C-UCFC206D1 |
| price | $ 162.40 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.40 |
| Manufacturer Name | NTN |
| Inch - Metric | Metric |
| Brand | NTN |
| Weight / LBS | 3.5 |
| Bore | 1.181 Inch | 30 Millimeter |
| EAN | 4547359036800 |
| Other Features | Single Row | Light Duty | Wide Inner Race | Open End | Spigot Joint | Has Flinger |
| Relubricatable | Yes |
| Global Part Number GPN | 554164 |
| Mounting Method | Set Screw |
| Length Thru Bore | 1.5 Inch | 38.1 Millimeter |
| Cartridge Pilot Diameter | 3.15 Inch | 80 Millimeter |
| Cartridge Pilot Depth | 0.315 Inch | 8 Millimeter |
| Bolt Spacing | 2.783 Inch | 70.7 Millimeter |
| Nominal Bolt Circle Diameter Round | 3.9 Inch | 99 Millimeter |
| Housing Style | 4 Bolt Round Flange Cartridge |
| Number of Mounting Holes | 4 |
| Mounting Bolts | 10 Millimeter |
| Insert Part Number | UC206D1 |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Seals | Single Lip Land Riding |
| Pilot Configuration | With Pilot |
