FREE SHIPPING on orders over $100
Offer price breaks when you order a larger quantify.
In Stock
Leading time would be depends on our work efficiency and delivery schedule, usually within 2 business days.
Specifications
| title | 22328-E1A-K-M-C4 |
| price | $ 3,145.86 / each |
| Category | Spherical Roller Bearings |
| UNSPSC | 31171510 |
| Harmonized Tariff Code | 84823080 |
| Manufacturer Name | SCHAEFFLER GROUP USA INC |
| Inch - Metric | Metric |
| Brand | FAG BEARING |
| Weight / LBS | 77.16 |
| Bore | 5.512 Inch | 140 Millimeter |
| EAN | 4054364592301 |
| Outside Diameter | 11.811 Inch | 300 Millimeter |
| Relubricatable | Yes |
| Seal Type | Open |
| Enclosure | Open |
| Global Part Number GPN | 477240 |
| Mounting Method | Adapter Mount |
| Cage Material | Bronze |
| Width | 4.016 Inch | 102 Millimeter |
| Internal Clearance | C4-Extra Loose |
| Number of Rows of Rollers | Double Row |
| Withdrawal Sleeve | AHX2328 (Specify bore) |
| Withdrawal Nut | KM31 |
| Adapter Part Number | SNW128 H2328 HA2326 HE2326 (Specify Bore) Inch | H2328 (Specify bore) Millimeter |
| Bore Profile | Tapered |
