Specifications
| title | 24152BC3 |
| price | $ 14,693.60 / each |
| Category | Spherical Roller Bearings |
| UNSPSC | 31171510 |
| Harmonized Tariff Code | 84823080 |
| Manufacturer Name | NTN |
| Inch - Metric | Metric |
| Brand | NTN |
| Weight / LBS | 260.78 |
| Bore | 10.236 Inch | 260 Millimeter |
| EAN | 4547359523577 |
| Outside Diameter | 17.323 Inch | 440 Millimeter |
| Relubricatable | Yes |
| Seal Type | Open |
| Enclosure | Open |
| Global Part Number GPN | 480056 |
| Mounting Method | Shaft Mount |
| Cage Material | Bronze |
| Width | 7.087 Inch | 180 Millimeter |
| Internal Clearance | C3-Loose |
| Number of Rows of Rollers | Double Row |
| Withdrawal Sleeve | Not Applicable |
| Withdrawal Nut | Not Applicable |
| Adapter Part Number | Not Applicable Inch | Not Applicable Millimeter |
| Bore Profile | Straight |
