Specifications
| title | 23030-E1-K-TVPB-C3 |
| price | $ 949.99 / each |
| Category | Spherical Roller Bearings |
| UNSPSC | 31171510 |
| Harmonized Tariff Code | 84823080 |
| Manufacturer Name | SCHAEFFLER GROUP USA INC |
| Inch - Metric | Metric |
| Brand | FAG BEARING |
| Weight / LBS | 15.432 |
| Bore | 5.906 Inch | 150 Millimeter |
| EAN | 4026677871558 |
| Outside Diameter | 8.858 Inch | 225 Millimeter |
| Relubricatable | Yes |
| Seal Type | Open |
| Enclosure | Open |
| Global Part Number GPN | 477415 |
| Mounting Method | Adapter Mount |
| Cage Material | Polymer |
| Width | 2.205 Inch | 56 Millimeter |
| Internal Clearance | C3-Loose |
| Number of Rows of Rollers | Double Row |
| Withdrawal Sleeve | AHX3030 (Specify bore) |
| Withdrawal Nut | KM32 |
| Adapter Part Number | SNW3030 H3030 HA3030 HE3030 (Specify Bore) Inch | H3030 (Specify bore) Millimeter |
| Bore Profile | Tapered |
