Specifications
| title | 7034BDB+15/G33P5 |
| price | $ 8,893.10 / each |
| Category | Precision Ball Bearings |
| UNSPSC | 31171531 |
| Harmonized Tariff Code | 8482.10.50.28 |
| Manufacturer Name | NTN |
| Inch - Metric | Metric |
| Brand | NTN |
| Bore | 6.693 Inch | 170 Millimeter |
| Outside Diameter | 10.236 Inch | 260 Millimeter |
| Seal Type | Open |
| Enclosure | Open |
| Precision Class | ABEC 5 | ISO P5 |
| Cage Material | Nylon |
| Width | 3.307 Inch | 84 Millimeter |
| Single Row/Double Row | Single Row |
| Preload | Special |
| Material - Ball | Steel |
| Contact Angle | 40 Degree |
| Raceway Style | 1 Rib Outer Ring |
| Flush Ground | Yes |
| Mounting Arrangement | Duplex-Back to Back |
