Specifications
| title | 6200ZZP5 |
| price | $ 208.97 / each |
| Category | Miniature Precision Ball Bearings |
| UNSPSC | 31171504 |
| Harmonized Tariff Code | 8482.10.50.68 |
| Manufacturer Name | NTN |
| Inch - Metric | Metric |
| Brand | NTN |
| Weight / LBS | 0.07 |
| Bore | 0.394 Inch | 10 Millimeter |
| Other Features | Single Row | Deep Groove |
| Outside Diameter | 1.181 Inch | 30 Millimeter |
| Seal Type | 2 Metal Shields |
| Enclosure | 2 Metal Shields |
| Precision Class | ABEC 5 | ISO P5 |
| Cage Material | Steel |
| Inner Race Width | 0.354 Inch | 9 Millimeter |
| Outer Race Width | 0.354 Inch | 9 Millimeter |
| Flange Outside Diameter | 0 Inch | 0 Millimeter |
| Single Row/Double Row | Single Row |
| Preload | None |
| Material - Ball | Steel |
| Contact Angle | 0 Degree |
| Raceway Style | Not Applicable |
| Enclosure Type | Non Contact Shield |
| Flush Ground | No |
| Flanges | No |
| Race Material | Steel |
