Specifications
| title | UG348L |
| price | $ 1,395.22 / each |
| Category | Insert Bearings Spherical OD |
| UNSPSC | 31171536 |
| Harmonized Tariff Code | 8482.10.50.00 |
| Manufacturer Name | LINK BELT |
| Inch - Metric | Inch |
| Brand | LINK BELT |
| Weight / LBS | 18 |
| Bore | 3 Inch | 76.2 Millimeter |
| Other Features | Single Row | Heavy Duty | Single Collar | With Set Screw |
| Outside Diameter | 6.693 Inch | 170.002 Millimeter |
| Relubricatable | Yes |
| Global Part Number GPN | 245418 |
| Mounting Method | Concentric Collar |
| Length Thru Bore | 4.406 Inch | 111.912 Millimeter |
| Outer Race Width | 1.772 Inch | 45.009 Millimeter |
| Inner Race Profile | Wide Inner Ring |
| Snap Ring | No |
| Outer Race Profile | Spherical |
| Seal Type | Steel Clad Clearance |
