Specifications
| title | INS-S2-111R |
| price | $ 225.04 / each |
| Category | Insert Bearings Spherical OD |
| UNSPSC | 31171536 |
| Harmonized Tariff Code | 8482.30.00.80 |
| Manufacturer Name | ABB MOTORS AND MECHANICAL INC |
| Weight / kgm | 1.212 |
| Inch - Metric | Inch |
| Brand | DODGE |
| Weight / LBS | 2.67 |
| Bore | 1.688 Inch | 42.875 Millimeter |
| Other Features | Double Row | With Set Screw | Has Flinger |
| Outside Diameter | 3.346 Inch | 84.988 Millimeter |
| Relubricatable | Yes |
| Global Part Number GPN | 560923 |
| Mounting Method | Concentric Collar |
| Length Thru Bore | 2.656 Inch | 67.462 Millimeter |
| Outer Race Width | 0.953 Inch | 24.206 Millimeter |
| Inner Race Profile | Narrow Inner Ring |
| Snap Ring | No |
| Outer Race Profile | Spherical |
| Seal Type | Triple Lip Rubbing |
