Specifications
| title | ZBR2315 |
| price | $ 1,945.58 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | REXNORD |
| Weight / kgm | 22.246 |
| Inch - Metric | Inch |
| Brand | REXNORD |
| Weight / LBS | 49 |
| Bore | 3.938 Inch | 100.025 Millimeter |
| EAN | 0698210595388 |
| Other Features | Double Row | Single Collar | With Set Screw |
| Relubricatable | Yes |
| Global Part Number GPN | 555669 |
| Mounting Method | Concentric Collar |
| Length Thru Bore | 5.188 Inch | 131.775 Millimeter |
| Cartridge Pilot Diameter | 8.125 Inch | 206.375 Millimeter |
| Cartridge Pilot Depth | 1.5 Inch | 38.1 Millimeter |
| Bolt Spacing | 6.625 Inch | 168.275 Millimeter |
| Nominal Bolt Circle Diameter Round | 9.4 Inch | 238 Millimeter |
| Housing Style | 4 Bolt Round Flange Cartridge |
| Number of Mounting Holes | 4 |
| Mounting Bolts | 3/4 Inch |
| Insert Part Number | 2315U |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Seals | Clearance Seal |
| Pilot Configuration | With Pilot |
