Specifications
| title | USFC5000E-203-C |
| price | $ 526.51 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | MORSE INDUSTRIAL |
| Inch - Metric | Inch |
| Brand | MORSE INDUSTRIAL |
| Weight / LBS | 10.2 |
| Bore | 2.188 Inch | 55.575 Millimeter |
| EAN | 662461362648 |
| Other Features | Double Row | Single Collar | With Set Screw |
| Relubricatable | Yes |
| Mounting Method | Concentric Collar |
| Length Thru Bore | 3.125 Inch | 79.38 Millimeter |
| Cartridge Pilot Diameter | 5 Inch | 127 Millimeter |
| Cartridge Pilot Depth | 1.469 Inch | 37.313 Millimeter |
| Bolt Spacing | 4.243 Inch | 107.772 Millimeter |
| Nominal Bolt Circle Diameter Round | 6 Inch | 152 Millimeter |
| Housing Style | 4 Bolt Round Flange Cartridge |
| Number of Mounting Holes | 4 |
| Mounting Bolts | 1/2 Inch |
| Insert Part Number | USI5000-203-C |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Expansion |
| Seals | Double Lip Contact |
| Pilot Configuration | With Pilot |
