IPTCI

IPTCI NANFL 208 40MM

  • Write a review
  • FREE SHIPPING on orders over $100
    • $42.88 each
    Offer price breaks when you order a larger quantify.

    In Stock

    Leading time would be depends on our work efficiency and delivery schedule, usually within 2 business days.
    Shipping:Ships in 2 business day
    CONTACT US

    Specifications


    title NANFL 208 40MM
    price $ 50.45 / each
    Category Flange Block Bearings
    UNSPSC 31171501
    Harmonized Tariff Code 8483.20.40.40
    Manufacturer Name IPTCI
    Inch - Metric Metric
    Brand IPTCI
    Weight / LBS 4.5
    Bore 1.575 Inch | 40 Millimeter
    Other Features Single Row | Standard Duty | Wide Inner Race
    Relubricatable Yes
    Global Part Number GPN 548087
    Mounting Method Eccentric Collar
    Length Thru Bore 2.217 Inch | 56.3 Millimeter
    Cartridge Pilot Diameter 0 Inch | 0 Millimeter
    Cartridge Pilot Depth 0 Inch | 0 Millimeter
    Bolt Spacing 5.657 Inch | 143.7 Millimeter
    Nominal Bolt Circle Diameter Round 5.7 Inch | 144 Millimeter
    Housing Style 2 Bolt Flange Block
    Number of Mounting Holes 2
    Mounting Bolts 7/16 Inch
    Insert Part Number NA208
    Housing Configuration 1 Piece Solid
    Housing Material Cast Iron
    Expansion / Non-expansion Non-expansion
    Seals B Seal
    Pilot Configuration No Pilot
