Specifications
| title | MBR5600 |
| price | $ 13,632.63 / each |
| Category | Flange Block Bearings |
| UNSPSC | 31171501 |
| Harmonized Tariff Code | 8483.20.40.80 |
| Manufacturer Name | REXNORD |
| Weight / kgm | 96.7 |
| Inch - Metric | Inch |
| Brand | REXNORD |
| Weight / LBS | 213 |
| Bore | 6 Inch | 152.4 Millimeter |
| EAN | 0698210829056 |
| Other Features | Double Row | Double Collar | With Set Screw |
| Relubricatable | Yes |
| Global Part Number GPN | 552942 |
| Mounting Method | Concentric Collar |
| Length Thru Bore | 8.125 Inch | 206.375 Millimeter |
| Cartridge Pilot Diameter | 14 Inch | 355.6 Millimeter |
| Cartridge Pilot Depth | 1.375 Inch | 34.925 Millimeter |
| Bolt Spacing | 8.25 Inch | 209.55 Millimeter |
| Nominal Bolt Circle Diameter Round | 16.5 Inch | 419.1 Millimeter |
| Housing Style | 6 Bolt Round Flange Cartridge |
| Number of Mounting Holes | 6 |
| Mounting Bolts | 7/8 Inch |
| Insert Part Number | 5600U |
| Housing Configuration | 1 Piece Solid |
| Housing Material | Cast Iron |
| Expansion / Non-expansion | Non-expansion |
| Seals | Heavy Contact |
| Pilot Configuration | With Pilot |
