Specifications
| title | NU316-E-TVP2-C3 |
| price | $ 379.42 / each |
| Category | Cylindrical Roller Bearings |
| UNSPSC | 31171547 |
| Harmonized Tariff Code | 8482.50.00.00 |
| Manufacturer Name | SCHAEFFLER GROUP |
| Weight / kgm | 4.32 |
| Inch - Metric | Metric |
| Brand | FAG BEARING |
| Weight / LBS | 9.524 |
| Bore | 3.15 Inch | 80 Millimeter |
| EAN | 4012801235310 |
| Other Features | High Capacity | Plain Inner Ring | 2 Rib Outer Ring | Medium Series | Cage on Outer Ring ID |
| Outside Diameter | 6.693 Inch | 170 Millimeter |
| Relubricatable | Yes |
| Global Part Number GPN | 449127 |
| Precision Class | RBEC 1 | ISO P0 |
| Width | 1.535 Inch | 39 Millimeter |
| Number of Rows of Rollers | Single Row |
| Retainer | Yes |
| Separable | Inner Ring - Both Sides |
| Bore Profile | Straight |
| Profile | Complete with Outer and Inner Ring |
| Snap Ring | No |
| Internal Clearance | C3-Loose |
