Specifications
| title | N3038-M1-R150-230 |
| price | $ 2,676.58 / each |
| Category | Cylindrical Roller Bearings |
| UNSPSC | 31171547 |
| Harmonized Tariff Code | 8482.50.00.00 |
| Manufacturer Name | SCHAEFFLER GROUP USA INC |
| Inch - Metric | Metric |
| Brand | FAG BEARING |
| Weight / LBS | 41.887 |
| Bore | 7.48 Inch | 190 Millimeter |
| EAN | 4012801403528 |
| Other Features | Standard Capacity | 2 Rib Inner Ring | Plain Outer Ring | Cage on Inner Ring OD |
| Outside Diameter | 11.417 Inch | 290 Millimeter |
| Relubricatable | Yes |
| Global Part Number GPN | 565717 |
| Precision Class | RBEC 1 | ISO P0 |
| Width | 2.953 Inch | 75 Millimeter |
| Number of Rows of Rollers | Single Row |
| Retainer | Yes |
| Separable | Outer Ring - Both Sides |
| Bore Profile | Straight |
| Profile | Complete with Outer and Inner Ring |
| Snap Ring | No |
| Internal Clearance | R150-230 |
