Specifications
| title | M1316EX |
| price | $ 443.05 / each |
| Category | Cylindrical Roller Bearings |
| UNSPSC | 31171547 |
| Harmonized Tariff Code | 8482.50.00.00 |
| Manufacturer Name | LINK BELT |
| Inch - Metric | Inch |
| Brand | LINK BELT |
| Weight / LBS | 7.462 |
| Bore | 4.001 Inch | 101.636 Millimeter |
| EAN | 662327107529 |
| Other Features | Standard Capacity | 2 Rib Outer Ring | Narrow Width | Medium Series | Cage on Outer Ring ID |
| Outside Diameter | 6.693 Inch | 170 Millimeter |
| Relubricatable | Yes |
| Global Part Number GPN | 450123 |
| Precision Class | RBEC 1 | ISO P0 |
| Width | 1.535 Inch | 39 Millimeter |
| Number of Rows of Rollers | Single Row |
| Retainer | Yes |
| Separable | No |
| Bore Profile | Straight |
| Profile | Roller Assembly with Outer Ring - No Inner Ring |
| Snap Ring | No |
| Internal Clearance | C0-Medium |
